Air Cooled Oil Cooler is now available in LUCKNOW
Air Cooled Oil Cooler – Efficient Heat Dissipation for Hydraulic Systems
At AS Trading – Precision Engineered Hydraulic & Heat Transfer Solutions, we supply high-performance Air Cooled Oil Coolers designed to efficiently dissipate heat from hydraulic oil, lubricating oil, transmission oil, and other fluids. Built for heavy-duty industrial applications, our oil coolers ensure optimal operating temperatures and extended equipment life.
Key Specifications of Air Cooled Oil Cooler
Cooling Capacity: 5 kW to 200 kW (customizable based on requirement)
Oil Flow Rate: 10 L/min to 600 L/min
Maximum Working Pressure: Up to 25 bar
Core Material: High-grade aluminium fins with copper/aluminium tubes for superior heat transfer
Fan Motor Power: 0.12 kW to 2.2 kW (energy-efficient)
Fan Type: AC or DC axial flow fan
Operating Voltage: 220V / 380V / 415V (AC) or 12V / 24V (DC)
Oil Inlet/Outlet Connection: BSP/NPT/SAE (as per requirement)
Temperature Control: Optional thermostat or bypass valve
Mounting Options: Horizontal / Vertical mounting frames
Noise Level: Low-noise fan design for quiet operation
Finish: Powder-coated frame for corrosion resistance
Features & Benefits
High Efficiency Cooling – Maintains oil temperature for better hydraulic performance
Compact & Durable Design – Saves space and ensures long operational life
Energy-Saving Fan Motors – Reduces power consumption
Low Maintenance – No water requirement, corrosion-resistant materials
Versatile Applications – Suitable for industrial, mobile, and agricultural equipment
Applications
Hydraulic Power Packs
Construction Machinery
Plastic Injection Moulding Machines
Industrial Gearboxes
Agricultural Harvesters
Wind Turbine Systems
Location: Plot No. 152, Khasra No. 901, Extended Lal Dora, Rohtak Road, Tikri Kalan, Nangloi 2, West Delhi
Email: sales@astradingdelhi.com
Call: 9818437522
AS Trading – Your Reliable Source for Hydraulic & Heat Transfer Solutions
